This article contains detailed information regarding zirconia ceramic and ZTA.
You will learn more about topics such as:
Zirconia ceramics, also known as zirconium dioxide ceramics, are renowned for their remarkable strength and durability. These materials offer outstanding hardness and resistance to wear and corrosion while avoiding the brittleness typically associated with ceramics. Among the various types of zirconia ceramics, those stabilized with yttria or magnesia are the most widely used.
Zirconia Toughened Alumina (ZTA) is a composite ceramic that combines alumina and zirconia. In this material, zirconia grains are embedded within an alumina matrix. ZTA offers enhanced strength and toughness compared to pure alumina, while being more cost-effective than pure zirconia.
Blending aluminum oxide with zirconium oxide greatly enhances the material's strength, toughness, hardness, and resistance to wear. The key to this improvement is a mechanism called transformation toughening, which boosts the ceramic's fracture toughness. Under stress, zirconia particles undergo a change in crystal structure, leading to volume expansion that helps seal any cracks.
Various forms of zirconia ceramics have been created to improve their characteristics across different phases. Manufacturers have tailored these phases to suit diverse applications. Among these variations is zirconia-toughened alumina, which is just one example of the different zirconia phases.
To enhance the stability and durability of zirconia, various oxides are introduced. Common stabilizers include yttrium oxide, cerium oxide, magnesium oxide, and aluminum oxide. Each of these additives modifies the material's properties and attributes.
CSZ exhibits exceptional toughness and durability, particularly in moist and wet conditions. With its impressive flexural and compressive strength, it is an ideal choice for manufacturing sensors, instruments, probes, pumps, and fluid control systems.
CSZ is employed in situations where low temperature degradation is a concern, as it is less susceptible to damage from molecular water and can endure elevated temperature environments.
Researchers are continually improving different zirconia ceramics by experimenting with various stabilizers and metals to optimize the inherent properties of zirconia.
FSZ is stabilized using yttrium, a silvery-white, soft, and malleable rare earth metal. It is ideal for high-temperature applications that require resistance to thermal shock, high fracture toughness, and superior corrosion resistance. A distinctive feature of FSZ is its selective permeability to oxygen ions, making it suitable for use in active membrane applications.
As zirconia transitions from monoclinic to tetragonal and then to cubic phases, it experiences a volume expansion that can cause cracking in the ceramic. Incorporating yttrium into the cubic phase helps stabilize it, enabling the material to withstand a broad range of temperatures.
PSZ, which has a cream hue, incorporates 10% magnesium oxide (MgO) as a stabilizer. It maintains its high toughness even at high temperatures. The microcrystalline grain structure of PSZ not only boosts its strength but also provides resistance to chemicals and heat.
PSZ items remain resistant to corrosion when exposed to high-temperature fluid streams, including strong acids and alkalis. Essentially, PSZ is chemically stable and boasts outstanding compressive and tensile strength.
A major benefit of PSZ is its ability to be machined into extremely intricate shapes, making it capable of performing functions where metals cannot operate. It is widely used for pump seals for caustic chemicals and friction stressed roller bearings.
TZP ceramics exhibit exceptional fracture toughness and hardness at ambient temperatures, along with impressive corrosion resistance at high temperatures. They are predominantly used in medical applications such as hip replacements and dental restorations. In industrial settings, TZP serves as a thermal barrier coating for fuel rod claddings.
Applications requiring TZP demand a material with exceptional strength, hardness, and a flawless microstructure. TZP’s thermal expansion coefficient is comparable to that of iron and iron-based alloys. Due to its remarkable fracture toughness, it is often termed "ceramic steel."
TTZ is known as "ceramic steel" because of its behavior under stress, which resembles that of steel rather than traditional brittle ceramics. The transformation toughening of zirconia ceramics utilizes martensitic phase transformation to alter the stress distribution within the material. This phase change enhances tensile stress and counters applied stress. When subjected to tension, zirconia ceramics undergo a phase transformation that expands the ceramic’s volume and reduces local stress, thereby inhibiting crack propagation and improving the material's toughness.
TTZ is frequently used in ceramic knives, which are twice as hard as conventional steel knives and feature ultra-sharp blades, making them ideal for precise and delicate cutting tasks.
ZTA ceramics are known for their chemical and thermal stability as well as their remarkable strength. The manufacturing process involves stress-induced transformation toughening, where strain is applied to zirconia, causing it to crack and interact with alumina particles. This strain and cracking result in a ceramic material with enhanced strength.
ZTA's applications are expanding rapidly and encompass valve seals, bushings, pump components, medical implants, and cutting tools. Its broad range of properties contributes to its versatility. ZTA's strength and corrosion resistance enable it to withstand heavy loads without significant degradation.
Optimizing the production process for zirconia ceramics and ZTA is crucial for achieving the best results. Fortunately, numerous manufacturers in the United States and Canada have refined this process. Below, we highlight some of the leading producers of this machinery.
The M1 Compact Milling Unit from Zirkonzahn is renowned for its versatility and precision in milling zirconia ceramics and various other materials. Its compact design makes it ideal for small laboratory environments. This machine features high-speed milling and 5-axis simultaneous machining, enabling the creation of intricate designs and efficient production.
The Ceramill Motion 2 by Amann Girrbach is a versatile milling machine designed for fabricating zirconia ceramics and other dental restorations. It boasts a fully automated 5-axis milling system for exceptional precision and accuracy. The machine also includes an advanced tool management system and supports a broad array of material blanks, making it adaptable for diverse applications.
The PrograMill One by Ivoclar Vivadent is a compact, user-friendly milling machine designed for zirconia ceramics and other materials. Its self-contained design includes an integrated PC and touchscreen, streamlining the workflow. Equipped with high-performance components, it delivers efficient milling with excep
The DWX-52DCi Dental Milling Machine by Roland DG is specifically designed for dental applications, including zirconia ceramics. It includes an automated disc changer for uninterrupted milling without manual intervention. The machine provides simultaneous 5-axis machining, allowing for the creation of intricate dental restorations with exceptional accuracy and detail.
The R5 Dental Milling Machine by VHF is a flexible milling solution ideal for zirconia ceramics and other materials. It features a spacious milling area that enables the simultaneous creation of multiple restorations. The machine includes an advanced tool management system and delivers high-speed milling with exceptional precision and reliability.
Availability of specific models may vary, so it's advisable to check with manufacturers or authorized distributors for the most current information on available models and their features.
The production of zirconia ceramics involves calcining zirconium, which entails heating the material to very high temperatures while controlling the oxygen exposure. The initial stages of the process focus on eliminating impurities and facilitating thermal decomposition.
Zirconia, also known as zirconium oxide, is a crystalline form of zirconium, a lustrous, grayish-white metal that is soft, ductile, and highly resistant to corrosion. Zirconium has been utilized for centuries in combination with other metals due to its ability to form stable compounds.
Preparing the composite powder involves several mixing techniques, such as mechanical mixing, multiphase suspension, sol suspension, and sol-gel methods. Each method has its own advantages and is selected to ensure thorough blending of the composite powder.
Mechanical Mixing – Mechanical mixing is straightforward but offers the least assurance of uniform dispersion of components. Typically, this method results in a mixture with high porosity, which can negatively impact the mechanical properties of the zirconia material.
Multiphase Suspension Mixing – This method begins by creating a single-phase suspension with dispersed components. The next step involves optimizing conditions to ensure that particles from each phase disperse uniformly. The resulting mixture is achieved using typical flocculation conditions, where the flocculant absorbs submicron flocs formed from the combined suspended materials, effectively bridging the gaps between them.
Sol Suspension – In sol suspension, a nano sol—a heterogeneous mixture—is used to blend suspensions. When the solid content is high, the sol can be stirred or heated to produce high-quality mixed nano composite ceramics.
Sol-Gel – The sol-gel process transforms small molecules into solid materials by first converting monomers into a colloidal solution, which then forms the gel. This method results in uniformly mixed nano powders.
The blended material is combined with a stabilizer to form a ball, which is then mixed with a small amount of binder and compressed under pressures ranging from 60 MPa to 100 MPa. This compaction process ensures that the zirconia oxide powder achieves close contact with the stabilizer particles.
The quality and preparation of zirconia ceramics for processing are greatly influenced by the sintering process, which involves heating the stabilized zirconia powder to temperatures exceeding 1000°C. Sintering can be carried out using various methods, with electric, high-pressure, activation, and hot press techniques being among the most common.
Sintering is a technique used to consolidate ceramic powder by heating the green compact to a temperature below its melting point, causing the zirconia particles to diffuse. This process reduces or eliminates the pores in the material, as illustrated in the diagram below.
Electric Field Sintering - Electric field sintering uses a direct current (DC) electric field. The green material is placed in direct contact with electrodes in the furnace. An electric field is activated until the flash phenomenon occurs. Densification happens quickly and radically reduces the sintering temperature.
High Pressure Sintering – This method involves sintering zirconia ceramic powder at extremely high pressures, reaching hundreds of thousands of atmospheres. It helps the material achieve high density, fine crystal structures, and alters its crystal, atomic, and electronic states. For successful high-pressure sintering, it is crucial to mold the materials, vacuum seal them, and use highly pure zirconia.
Activation Sintering – Activation sintering employs physical or chemical techniques to elevate the energy state of the reactant molecules during and before sintering. Physical methods include the use of electric fields, magnetic fields, ultrasonic waves, and radiation. Chemical methods involve redox reactions, and the use of dissociation oxides, halides, and hydroxides. This approach allows for reduced sintering temperatures, shorter sintering times, and enhanced sintering effects.
Hot Press – Hot press sintering builds on activation sintering technology. This process leverages the activated state of the reactants from the activation stage and applies higher energy during the decomposition phase. It results in a higher density ceramic material, achieved at significantly lower temperatures, reduced pressures, and shorter processing times.
This design represents an exceptionally efficient hot pressing method.
Cold Sintering – Lowering sintering temperatures is a key approach to reducing carbon emissions from industrial processes. Various methods have been developed to address this need and comply with evolving air quality standards.
Cold sintering involves using a liquid to facilitate the rearrangement and interdiffusion of particles under moderate pressure and low heat. In this process, powdered material is combined with a liquid in which it is partially soluble. The wet mixture is then placed in a die and subjected to pressures ranging from 100 MPa to 500 MPa while being heated to temperatures below 300°C. As heat and pressure are applied, the solid material precipitates. Currently, this method is not applicable to all zirconia ceramic materials.
Machining sintered zirconia ceramics is essential for preparing the material for various applications. However, machining zirconia ceramics presents challenges due to its remarkable hardness, which is comparable to steel. The bending strength and fracture toughness of zirconia ceramics can be adversely affected by heat or elevated temperatures. To address these challenges, high-speed cutting tools operating at speeds between 500 meters per minute (m/min) and 670 m/min are used. Increased cutting speeds also help reduce flank wear on the tools.
Machining zirconia ceramics requires specialized cutting tools, such as natural diamonds, polycrystalline diamonds, chemical vapor deposition (CVD) diamonds, and cubic boron nitride tools.
Natural Diamond (ND) – ND tools are employed for preparing turning tools.
Polycrystalline Diamond (PCD) – Developed in the 1970s, PCD is a hard material known for its outstanding mechanical, thermal, chemical, and electrical properties. It is a crucial tool in cutting processes, offering high-speed cutting with exceptional stability and precision. One of its major advantages is its capability for dry cutting.
Chemical Vapor Deposition (CVD) – CVD cutting tools are particularly effective for machining zirconia ceramics, as they excel in cutting materials that generate powder during the process. They are mainly used in applications where cutting is abrasive and needs to minimize chipping.
Cubic Boron Nitride (PCBN) – PCBN tools, with a structure similar to that of diamonds, offer comparable performance. They can be shaped in various forms and provide material removal and wear resistance similar to diamonds, but at a lower cost.
The hardness and strength of zirconia ceramics make them suitable for a wide range of applications. They are commonly used in prosthetic dentistry, bone replacements, automotive parts, and high-altitude aircraft. The versatility of zirconia ceramics allows engineers to develop innovative designs and functionalities.
In addition to grinding and cutting, zirconia ceramics can be shaped and formed using injection molding, laser shaping, and cutting techniques. Injection molding is ideal for high-end, high-volume production, while laser cutting is typically used for smaller production runs.
Zirconia toughened alumina (ZTA) is employed in all the applications where zirconia ceramics are used. Its broad range of properties makes ZTA suitable for various fields, including medical applications and as a material for pumps, valve seals, bushings, cutting tools, and engine components. Its ability to withstand heavy loads without degradation makes it particularly useful for load-bearing applications.
Wherever zirconia ceramics are used, zirconia toughened alumina (ZTA) is often employed as an upgrade or essential component.
In dentistry, three types of zirconia ceramics are commonly used: tetragonal zirconia polycrystal, magnesium-stabilized zirconia, and zirconia toughened alumina (ZTA). These zirconia ceramics offer the necessary properties for effective tooth restoration. They are aesthetically pleasing and possess the strength required for dental applications, representing a significant advancement over mid-20th-century metal dental materials, as they do not cause allergic reactions.
Zirconia is used in dentistry for applications such as posts, crowns, bridges, and implants.
Dental Posts – Zirconia ceramic dental posts are preferred for restoring anterior teeth due to their aesthetic appeal. Since the 1990s, they have replaced metal posts, which often caused gray discoloration. Zirconia ceramic posts also prevent corrosive reactions in the mouth and surrounding tissues, avoiding issues such as burning, pain, and a metallic taste.
Crowns – Zirconia crowns are preferred over metal and gold crowns for their strength, durability, and aesthetic appeal. They can be made as full, translucent, or layered zirconia crowns. The versatility of zirconia ceramics allows for cementation or screw installation. Additionally, their robust nature makes them suitable for patients who grind their teeth or chew forcefully.
Abutments – Zirconia ceramic abutments are favored for their versatility, enabling custom design through CAD or wax impressions for a precise fit. In cases of thin gingival tissue, zirconia abutments help block light from exposing the abutment, preserving the aesthetic appearance. Additionally, their color can be adjusted to match adjacent teeth.
Zirconia Ceramic Brackets – Polycrystalline zirconia ceramic brackets are an alternative to alumina ceramic brackets and a replacement for metal brackets. In orthodontics, these brackets are used to secure the wires of braces, helping to keep them off the teeth and facilitating tooth movement.
Dental Implants – Approved for use in 2011, zirconia ceramic dental implants are known for their biocompatibility and exceptional stability. Unlike metal screws, which often lacked aesthetic appeal and could cause allergic reactions or sensitivities, zirconia implants avoid dark lines along the gum line and come in various configurations to suit different needs.
Moreover, metal-free zirconia ceramic implants are advantageous for gum health as they retain less plaque and calculus, particularly with one-piece implants. The outstanding flexural strength and fracture toughness of zirconia ceramics ensure a secure and durable fit.
Dense zirconia ceramics are used for joint replacements, especially for wear resistant bearing surfaces. Zirconia ceramics have mechanical advantages over metal alloys and can be polished to an exceptionally smooth finish. The ability of the material to be scratch resistant as a bearing surface is highly beneficial.
The most common material used to produce ceramic bearing materials is ZTA, which has a wear resistance comparable to metal and has become the first choice for hip joint replacement.
Hip Joints – Hip joints are ball-and-socket joints, with the socket formed by a cup surrounding the ball, protected by cartilage and lined with a membrane. Damage to the blood supply can weaken the bone and lead to collapse. In advanced cases, hip joint replacement becomes necessary. While the stems and support sockets are typically made of steel or titanium, the heads and sockets are often made from zirconia ceramics due to their exceptional strength and durability, which is particularly beneficial for early-life hip replacements.
Knee Replacement – Zirconia ceramics are used in knee replacements, especially when arthritis causes joint pain. Studies of total knee arthroplasty with zirconia ceramics have demonstrated significant improvements in knee movement. Research confirms that zirconia ceramics offer an excellent survival rate and enhance joint functionality.
Zirconia ceramic cutting blades are ideal for slicing through materials like paper, aluminum, and steel. They produce fewer leftovers, have a low reject rate, and require less frequent replacement. Thanks to their high hardness, fine grain structure, and steel-like strength, these blades are exceptionally durable. Additionally, they resist corrosion, erosion, and wear, making them suitable for various environments.
Zirconia ceramic bearings are resistant to wear, corrosion, high temperatures, extreme cold, and magnetoelectric fields. They do not require oil lubrication, making them suitable for extreme and harsh environments. Traditionally used in cooling fans, zirconia ceramic bearings have proven to offer long life and noise stability, making them ideal for use in computers.
For many years, most valves were made of metal. However, the corrosion susceptibility of metal has led to significant damage, reducing the working life and reliability of these valves and adversely affecting system and process performance.
Pipelines transport various chemicals and materials, including hydrogen sulfide, carbon dioxide, and organic acids found in oil, gas, and reservoir water. These substances can be highly corrosive and damaging to metal surfaces, leading to rapid deterioration. Zirconia ceramics, with their exceptional resistance to wear, corrosion, temperature fluctuations, and thermal shock, have proven to be an ideal replacement for metal valves in such demanding environments.
Zirconia ceramic grinding beads, made from yttrium-stabilized zirconia, are renowned for their superior crystallization and performance. They are widely used in applications that require ultra-fine grinding and dispersion, such as in paints, coatings, electronic materials, and magnetic materials.
Zirconia ceramic beads are ideal for grinding due to their shortened grinding times, high hardness, and exceptional toughness. Their nonporous, smooth surfaces and roundness make them suitable for high-viscosity materials and contribute to their fine grinding capabilities.
Zirconia ceramic crucibles are used as refractory and insulating containers capable of withstanding temperatures up to 1900°C and beyond. They are specifically designed for melting superalloys and precious metals due to their chemical inertness, excellent thermal shock resistance, and ability to handle temperatures as high as 2200°C.
Zirconia ceramic crucibles are either fully stabilized with yttrium or partially stabilized to enhance corrosion and wear resistance. They come in various sizes, with capacities ranging from 2 mL to 300 mL, heights from 15 mm to 80 mm, and wall thicknesses from 1.5 mm to 3.5 mm.
The shock resistance, high temperature strength, porosity, and surface area of zirconia ceramics make them capable of absorbing impurities from molten metal while preventing bubbles in the metal. This factor reduces turbulence making it possible for the metal to be homogenized. Zirconia ceramic filter plates can be coated with catalysts. While the impurities are being removed, chemical reactions are conducted to improve the quality of the metal casting.
The thirteen applications of zirconia and ZTA ceramics mentioned above represent just a small portion of their many uses. Due to their exceptional durability, toughness, and strength, zirconia and ZTA ceramics are employed in various fields, including aerospace and automotive industries, where their lightweight and robust properties are highly valued. They are also utilized in pump components, insulation, and heating elements. Ongoing research and innovation continually uncover new and practical applications for these versatile materials.
The grading of zirconia ceramics depends on the kind of stabilizing agent incorporated, such as yttria, alumina, magnesium, or cerium. These stabilizers are added to minimize the risk of cracking in zirconia ceramics when their volume expands beyond 9%. This is achieved by replacing Zr+4 ions in the crystal structure with ions that are slightly larger.
YSZ stands out as one of the most robust zirconia ceramics, offering the highest flexural strength among its peers. Its chemical resistance makes it suitable for applications in the food and cosmetic sectors. On the Mohs hardness scale, YSZ is rated above 9, with diamond being the hardest at 10.
YSZ's exceptional wear resistance ensures that it remains uncontaminated during processes such as milling, grinding, or dispersion. With a density exceeding 6 grams per cubic centimeter, it ranks as one of the densest ceramic materials available.
ZTA ceramics provide enhanced strength and durability at a more affordable price compared to other zirconia ceramics. By blending aluminum oxide with 10 to 20% zirconium oxide, ZTA achieves greater strength, toughness, hardness, and wear resistance than alumina on its own. The primary improvement in the material comes from transformation toughening, which greatly boosts the fracture toughness of ZTA.
Under stress, zirconia particles undergo a transformation from a tetragonal to a monoclinic crystalline structure. This structural change results in volume expansion, which helps to close cracks within the alumina matrix. This transformation enhances ZTA’s suitability for applications that demand high structural strength.
MSZ contains tiny tetragonal phase precipitates within its cubic phase grains. When a crack develops in the material, these precipitates transform from a metastable tetragonal phase to a stable monoclinic phase. This phase change causes the precipitates to expand, effectively closing the cracks and enhancing the material's toughness.
The color of MSZ, which can range from ivory to yellowish-orange, depends on its preparation method. Ivory-colored MSZ is highly pure and boasts superior mechanical properties. It remains stable at temperatures up to 220°C and is well-suited for environments with high moisture levels.
CSZ is specifically engineered for applications in humid environments, thanks to its exceptional strength and toughness. It is ideal for use in sensors, instrumentation, probes, pumps, and fluid control systems. With its minimal degradation at low temperatures and reduced sensitivity to water, CSZ stands out as the most effective zirconia ceramic for wet conditions.
