Introduction
This article will take an in-depth look at sand casting.
The article will bring more detail on topics such as:
Sand Casting, its Construction, and Methods
Types of Casting Sand
Applications and Advantages of Sand Casting
And Much More…
Chapter 1: How is sand casting constructed, and what methods are used in the process?
Originating around 1000 BCE, sand casting is one of the oldest metal casting techniques. Throughout history, advancements in process controls, material options, and design intricacies have refined the method. These developments have enhanced its versatility, making sand casting the most prevalent and adaptable metal casting technique in use today.
What is Sand Casting?
In sand casting, molten metal is poured into a sand mold that has been shaped into the desired form. After the metal cools and solidifies, the sand mold is broken and removed. Materials commonly used for sand casting include metal, concrete, epoxy, plaster, and clay.
Casting is a manufacturing method where a liquid material is poured into a mold that contains a hollow cavity in the desired shape, and then allowed to harden. Common casting materials include metal, concrete, epoxy, plaster, and clay. This discussion will primarily focus on sand casting.
Parts produced through sand casting vary widely in size, weight, and complexity, utilizing a diverse range of metals. Sand as a casting material helps significantly lower the overall costs of the process, especially compared to metal mold casting, where mold machining represents a major expense.
The type of sand employed in sand casting depends on whether it will be reused or discarded. In green sand casting, molds can be reused, whereas in dry sand casting, the sand is typically discarded.
Sand casting is particularly suited for metals with high melting points, such as titanium, steels, and nickel, making it the preferred method for industries like aerospace and automotive that need cost-effective, small-batch parts.
Components of a Sand Casting Mold
Creating a sand casting mold typically involves four key components:
Base Sand
The base sand forms the foundation of the mold and is used in its purest state. To ensure the sand holds together, a binding agent is added. The core, which is also made from base sand, is essential in this process. Common types of base sand include:
Silica sand
Olivine sand
Chromite sand
Zircon sand
Chamotte sand
Binders or Binding Agents
Binding agents act as the adhesive that holds the sand particles together. Here are some of the most commonly used types of binders:
Clay and water
Oil
Resin
Sodium silicate
Improvement Through Additives
Additives enhance various aspects of the mold, including surface finish, strength, heat resistance, and cushioning properties.
Parting Compounds
This can be a fine powder or liquid that helps with the removal of the pattern from the mold.
Sand Casting Methods
Sand casting is a time-honored manufacturing technique that originated in China around 1600 BCE. Initially employed to create statues, decorative items, and artifacts, its role expanded significantly with the advent of airplanes and automobiles in the 20th century. This process became crucial for producing parts with precise accuracy and exceptional tolerances. Over time, ancient sand casting methods have been refined and adapted, making them integral to modern manufacturing of parts and components.
It is estimated that 70% of metal castings in the world are completed using sand casting. It is an essential production method for the manufacturing of engine blocks, cylinder heads, pump housings, valve bodies, and gearboxes.
Bedding-In Sand Casting
The 'bedding-in approach' is a technique used to create a solid cylindrical mold. This method involves partially filling the drag with molding sand and ramming it. Once enough ramming is done, the pattern is pressed into the sand. To ensure proper packing, the sand around the pattern is compacted tightly.
After removing the pattern, the sand is inspected for any soft spots on the surface. If soft patches are found, additional ramming is done to pack the sand more firmly. The pattern is then pressed down again to ensure a well-packed mold chamber.
During the bedding-in process, the dividing line should be level with the surrounding smooth sand surface. The drag does not need to be rolled over when using this method. Bedding-in is also applicable when using pit molding for larger molds.
False Cope Sand Casting
The false cope technique is another method for creating solid cylindrical molds. In this process, sand is tightly rammed beneath the pattern, while the pattern itself is bedded into the coping without focusing on the sand below. This results in a smooth parting surface.
Once the cope and pattern are dusted with separating sand, the drag section of the flask is placed on top of the cope and the standard ramming process is carried out. The assembly is then gripped, rolled onto a sand bed, and the clamps, cope, and bottom board are removed. The empty cope is placed on the drag and rammed. Here, the cope acts as a dummy block to create the drag and is known as a 'false cope.'
Flat Back Sand Casting
In flat back sand casting, the mold cavity is created on either the drag side, the cope side, or both. When dealing with an unmolded cope, a sprue is placed in the drag to facilitate pouring and cooling of the molded part. The pattern is placed in the drag box, covered with sand, and rammed. This method is used for simple flat back parts or for parts that will be joined with their other half when the cope and drag are assembled.
For simple flat back parts, the rammed pattern is removed, and gates and sprues are added to allow molten metal to enter the mold. When the pattern is in both the cope and drag boxes, the cope is placed over the drag box, and a similar or identical pattern is positioned and rammed, forming a complete impression.
After separating the cope and drag boxes and removing the patterns, the boxes are reassembled and sealed tightly to prevent the upper box from floating. Gates and sprues are then added for metal pouring. Once the metal has cooled and solidified, the part is removed and finished.
Skin Dried Sand Casting
In skin dried sand casting, a thin layer of sand is applied over the mold cavity and dried using heat sources like heaters, torches, heat lamps, or natural air. This dried layer, consisting of fine-grain sand mixed with a binder, creates an exceptionally smooth surface finish. The molten metal is then poured into the mold cavity, filling the space between the pattern and the dried skin layer.
As with other sand casting methods, the sand is removed once the part has cooled and solidified. This process is particularly suitable for parts requiring a very smooth and uniform surface, such as those used in aerospace, engine components, and machinery.
Water Glass or Sodium Silicate Sand Casting
Sodium silicate sand casting is a type of green sand casting that uses sodium silicate as the binder. This method allows for quick mold production by curing the sand and sodium silicate with carbon dioxide (CO2), which rapidly hardens the mold. Additional materials like resins, oils, cellulose, or polysaccharides may be mixed with sodium silicate to facilitate mold removal.
Sand mixed with sodium silicate is packed around the pattern, and CO2 is used to cure and harden the mold. After the mold sets, the pattern is removed, and molten metal is poured in. Once the metal has solidified, the part is removed from the mold and the sand is disposed of.
Water glass sand casting is effective for creating complex and detailed parts due to the mold's ability to form intricate shapes. While it is a cost-effective process with minimal machinery, it typically produces rough and uneven surfaces that may require additional finishing.
Vacuum Sand Casting
Vacuum sand casting, or the V-process, involves using a thin plastic sheet placed over a pattern with ventilation to allow vacuum extraction. A vacuum flask is positioned over the plastic-covered pattern, and sand is vibrated into the flask to compact it. A sprue and pour cup are added to the cope, and another plastic sheet is placed over the sand. A vacuum is then drawn through the sheets to harden and strengthen the sand.
The process is repeated for the drag, and molten metal is poured while the cope and drag remain under vacuum. The plastic vaporizes as the metal solidifies, maintaining the sand's shape. After cooling, the vacuum is released.
Vacuum sand casting is known for its precision with tolerances of ±0.01 inches and ±0.002 inches for thin cross-sections as narrow as 0.090 inches (2.3 mm). It offers excellent surface finishes without moisture defects, binder costs, or toxic fumes.
Shell Sand Casting
Shell sand casting involves creating a resin-coated sand mold that is heated until it hardens. Once the shell mold is formed, it is assembled, and molten metal is poured into it and allowed to cool. After cooling, the shell is broken away, and the part is retrieved.
Compared to traditional sand casting, shell sand casting is more expensive but offers higher accuracy and efficiency. It involves fewer steps, generates less waste, and is cost-effective for producing precise parts quickly in large quantities.
The key feature of shell sand casting is its resin-coated molds, which provide greater precision and accuracy than conventional sand casting. It allows for the rapid manufacturing of intricate and detailed components with smooth surfaces and precise dimensions, eliminating the need for secondary finishing.
How Sand Casting is Done
Sand casting involves several steps, including:
Producing the Pattern – Desired Product
A reusable pattern that replicates the details of the final product is used in sand casting. The pattern is made larger than the final part to accommodate thermal contraction or shrinkage. This allowance accounts for the volume reduction that occurs as the casting cools to room temperature.
Liquid shrinkage refers to the reduction in volume when metal transitions from a liquid to a solid state. To counteract this, a riser is used in the mold to supply additional liquid metal. Solid shrinkage occurs when metal contracts as it solidifies, and shrinkage allowances in the pattern help accommodate this change.
The machining allowance accounts for the additional material that will be removed to achieve the final product. This process involves eliminating the rough surface of the cast part. Factors such as the size, material properties, distortion, finishing accuracy, and the machining method affect the machining allowance. To facilitate safe pattern removal, all surfaces parallel to the direction of pattern extraction are tapered inward slightly, which is referred to as draft allowance.
Pattern Creation – Gates and Risers: Metal Delivery System
The pattern also includes metal channels for proper gating and risers, which ensure the cast product design is fed with metal efficiently. These channels control the metal flow and incorporate gas venting while directing thermal contraction to acceptable areas, away from the final finished product.
Patterns are made from various materials, such as wood, metal, synthetics, expandable polystyrene (EPS), and others, depending on the volume and tolerance needed. For components with hollow interiors, like pipe fittings, additional patterns called cores must be created.
Core Making
Cores are distinct parts of the mold designed to prevent the liquid material from filling gaps, allowing for the creation of interior cavities and other features that the main mold cannot produce. A core box is the tool used to form the core, essentially the mold for the core itself.
Core materials must meet specific requirements:
It must be strong enough to withstand the turbulence caused by the molten material
It must have a good hardness
It must have a high permeability so that the gasses formed during the casting process can easily escape
It must be able to withstand the high temperatures caused by the molten material
Smooth surface finish
Minimal gas formation when exposed to the molten material
It must be weak enough to break while the molten material cools and shrinks, allowing it to be removed after solidification.
Creating the Mold
A refractory material, such as sand, is used around the design, which must be stable at high temperatures. This material needs to be robust enough to support the weight of the molten metal during casting while being resistant to reactions with the metal. Additionally, it should be sufficiently brittle to be removed easily after the casting has cooled.
A variety of sand materials can be used to make the mold. Typically, additives like clay or chemical binders are mixed with the sand to enhance its strength and durability for the pouring process. Alternatively, the mold can be created by drilling the desired shape directly into a block of sand. This method is particularly useful during product development or for components with limited use, as it allows for rapid design changes without the need for storing or maintaining physical patterns.
The mold is generally divided into two parts: the "cope" (the top half) and the "drag" (the bottom half). Once the sand has hardened, the pattern is removed. To improve surface finish and protect the mold from metal turbulence during pouring, a refractory coating is applied. The two halves are then reassembled to form a cavity in the shape of the pattern. Cores may be included in the mold to create specific internal features in the final product.
Pouring the Metal into the Mold
Molten metal is poured directly into the stationary mold, filling the voids and defining the finished component along with the risers. The risers provide a continuous supply of liquid metal to the casting, allowing the metal to cool and solidify in a controlled manner. Since risers are designed to solidify last, they accommodate any shrinkage and potential voids, thus minimizing imperfections in the final part.
This method ensures smooth metal flow into the casting with reduced turbulence, which helps prevent oxide formation and other casting defects. It is suitable for producing almost any type of alloy. For highly reactive metals, an argon shielding process can be employed to protect the molten metal from exposure to air.
Shakeout Operation
Once the casting has hardened and cooled, it includes both the finished component and excess metal. During the shakeout process, the sand is broken apart. The sand used for molding is collected, reconditioned, and reused in large quantities.
Casting Final Operations
The gates, runners, and risers are removed from the casting, and additional finishing processes like sandblasting, grinding, and other methods are applied as needed to achieve the final dimensions. Sand castings may also require additional machining to meet precise dimensions or tolerances.
Heat treatment can enhance the dimensional stability or properties of the parts. Non-destructive testing (NDT) methods, such as fluorescent penetrant, magnetic particle, and radiographic inspections, are also utilized. Before shipment, final inspections for dimensions, alloy composition, and NDT results are completed and validated.
Chapter 2: Who are the leading manufacturers of sand casting machines?
The objective of the sand casting process is to produce parts with high precision and tolerance capabilities. Fortunately, numerous manufacturers have refined sand casting machines to achieve these goals. Below, we highlight five brands of sand casting machines used in the United States and Canada, including specific models and their distinctive features:
Hunter Foundry Machinery Corporation
Model: HLM Series Molding Machines
Features: The HLM Series is known for its high-speed and high-pressure molding capabilities. With a horizontal parted design, these machines ensure excellent mold integrity and reduce the likelihood of casting defects. They are equipped with advanced control systems for precise sand compaction and operate with energy efficiency. Additionally, the HLM Series provides versatility in molding sizes and pattern changes.
Sinto America
Model: FBO Flaskless Molding Machine
Features: The FBO Flaskless Molding Machine provides a versatile and efficient approach to sand casting by removing the need for flask handling, which enhances productivity. It includes automatic functions for mold handling, compaction, and release. The machine is equipped with a user-friendly touchscreen interface, programmable casting parameters, and requires minimal maintenance.
DISA Group
Model: DISAMATIC C Line Molding Machine
Features: The DISAMATIC C Line is a high-performance vertical molding machine that utilizes vertical molding technology paired with a matchplate system. It provides rapid cycle times, precise sand compaction, and accurate pattern alignment. The machine is equipped with automatic mold handling, advanced control systems, and excels in producing complex castings with high dimensional precision.
Roberts Sinto Corporation
Model: FDNX Series Flaskless Molding Machine
Features: The FDNX Series is a range of advanced flaskless molding machines designed for various sand casting applications. These machines provide high-speed molding, reliable mold compaction, and accurate pattern alignment. They include automatic mold handling, customizable casting parameters, and a modular design that facilitates easy customization and maintenance.
Palmer Manufacturing & Supply, Inc.
Model: No-Bake Shakeout System
Features: The No-Bake Shakeout System by Palmer Manufacturing & Supply is engineered for effective sand reclamation in no-bake sand casting processes. It employs mechanical vibration and air separation to extract sand from castings. The system includes adjustable shakeout intensity, integrated sand cooling, and automatic sand collection and disposal. This system is designed to reduce sand waste and enhance casting quality.
Please be aware that availability and specific models may change over time. For the most current product offerings, it's advisable to consult with the respective manufacturers.
Chapter 3: What are the different types of casting sand?
Sand casting is a highly versatile manufacturing technique, offering developers, designers, and engineers the flexibility to produce complex and detailed parts with precise tolerances. Its compatibility with various metals makes it the most widely used casting process.
Green Sand
Green sand casting is the most prevalent type of sand casting. Despite the name, the sand isn't actually green; it's termed "green" because of its moisture content. This sand mixture, which includes sand, clay, water, and various additives, is used to create molds that are reusable and suitable for high-volume production. However, the sand itself is not recyclable and is discarded after use.
In green sand casting, the composition typically includes 75% to 85% sand, 5% to 11% clay, 2% to 4% water, and 3% to 5% other materials like silica. The clay and water serve as binding agents, providing strength to the mold. While green sand casting is efficient for large quantities, it does not yield parts with tight tolerances or precise dimensions, often necessitating additional finishing processes.
Dry Sand
Dry sand casting involves mixing sand with clay or other binding agents, shaping it into the mold form, and then baking it to enhance its strength. The baking step is crucial and must be carefully managed to meet the specifications of the binder used. This method is commonly employed for casting large ferrous and non-ferrous components such as engine blocks, housings, gearboxes, and agricultural machinery parts.
Dry sand casting is favored for its ability to produce detailed designs with very precise tolerances. Similar to green sand casting, cores and sprues are utilized to channel the molten metal into the mold. Although the process is more complex, time-consuming, and costly, it delivers high-quality results. Unlike green sand casting, the sand used in dry sand casting is discarded after the casting is complete and cannot be reused.
Facing Sand
Face sand is employed to coat the mold surface, as suggested by its name. Typically composed of silica sand and clay, face sand is never sourced from previous casting projects. It is applied directly adjacent to the pattern's surface. Due to its direct exposure to the hot molten metal, face sand must possess high refractoriness and strength. This type of molding sand ensures an exceptionally fine grain finish in the mold.
Core Sand
Core molding sand is a mixture of silica sand with core oil (comprising linseed oil, resin, and mineral oil) and additional binding agents such as dextrin, cornflour, and sodium silicate. This blend is specifically used for making cores due to its excellent compressive strength.
Loam Sand
Loam sand consists of an equal mix of sand and clay, combined with sufficient water. It is commonly used for casting large, heavy components such as hoppers and turbine parts.
Parting Sand
Parting sand, which is pure silica sand, is applied to the surface of the design before the molding process. It is sprinkled over the pattern before embedding it in the molding sand. Additionally, this sand is spread across the contact surfaces of the cope, drag, and cheek to ensure smooth separation and prevent sticking.
Backing and Floor Sand
This type of casting sand, known as floor sand, is used to fill the volume box and support the facing sand. It provides backing and stability during the molding process.
System Sand
This type of molding sand is ideal for large mechanical castings due to its high refractoriness, permeability, and strength. System sand is used for machine molding to completely fill the flask. Unlike other sands, it does not require facing sand because it is pre-cleaned and contains special additives.
Molasses Sand
This molding sand uses molasses as a binding agent and is typically employed for creating cores and sometimes for intricate shape castings.
Leading Manufacturers and Suppliers
Chapter 4: What metals are commonly used in sand casting?
Sand casting is a highly adaptive process that can form any metal alloy including ones with high melting temperatures, such as steel, nickel, and titanium. The most common types of metals are aluminum, brass, cast iron, and cast steel. The choice of metal for casting determines the design functionality of the completed part and affects the casting’s quality, performance, and properties.
Factors such as production deadlines, quantities and volumes of parts, and varying cooling and solidification rates influence the choice of metal. Important properties considered in the selection process include corrosion resistance, thermal conductivity, hardness, and the metal's response to temperature changes.
Non-Ferrous Metals
Aluminum
Aluminum encompasses a variety of alloys that are lightweight, machinable, and offer strength comparable to mild steel while being less dense. Its favorable properties for casting include excellent castability, low density, and high corrosion resistance. The base sands used for aluminum casting include silica, olivine, chromite, zircon, and chamotte, which are mixed with binders such as clay, oil, resin, and sodium silicate.
Bronze
As with aluminum, bronze is a term used to describe several alloys of copper and tin that are altered by the percentage of copper, the percentage of tin, and the addition of other alloys such as aluminum, zinc, nickel, and iron. The three types of bronze used for sand casting are aluminum bronze, manganese bronze, and silicon bronze.
Aluminum Bronze consists of 9% to 12% aluminum and 4% to 6% iron and nickel with the remaining percentages being bronze. As is characteristic of bronze, aluminum bronze is corrosion and wear resistant with exceptional strength and toughness.
Manganese Bronze has 55% to 65% copper, 20% to 25% zinc, 1% to 5% manganese, and 1% to 5% iron and has a resistance to corrosion, excellent strength with wear resistance, and extraordinary mechanical properties.
Silicon Bronze is a bronze alloy with 96% bronze and 4% silicon, which makes it easy to machine and cast. It is normally used to produce ball bearings, bearing cages, spacers, gears, and parts of valves.
Brass
Brass, an alloy of copper and zinc, varies in properties based on the proportions of these metals, affecting its characteristics and appearance. Its resistance to rust and corrosion is attributed to the absence of iron or iron oxide, combined with the zinc and copper content.
Brass's high copper content provides excellent conductivity and tensile strength, making it both easy to bend and form. Its ability to maintain exceptional strength after molding contributes to its popularity in casting applications.
Zinc
Zinc sand casting enables the production of components with thinner walls, fewer draft angles, and long, narrow holes. Zinc is alloyed with copper, aluminum, and magnesium to enhance its strength, rigidity, castability, and toughness. While zinc is easier to work with than aluminum, it is approximately two and a half times heavier. Like aluminum, zinc offers excellent corrosion resistance.
Zinc's high hardness allows for the creation of parts with thin walls and complex shapes that maintain tight tolerances and long-lasting utility.
Lead
Lead has been used in sand casting since Roman times. It is a heavy metal known for its corrosion resistance. However, the use of lead in sand casting requires careful handling due to health risks associated with inhalation. Many countries have established standards to limit the amount of lead used in manufacturing.
Despite its health concerns, lead is still employed in sand casting today, primarily for producing small to medium-sized parts such as plumbing fittings and decorative items.
Copper
Copper is typically alloyed with other metals to improve its mechanical and physical properties. While stronger and more expensive than aluminum, copper offers high tensile strength and excellent electrical and thermal conductivity. Its resistance to corrosion makes it suitable for a wide range of products.
Like lead, copper has been used for thousands of years to manufacture various home and industrial products. Sand casting remains an economical method for producing copper items in large quantities, such as plumbing fixtures and hardware.
Ferrous Metals
Iron
Iron is well-suited for casting due to its fluidity, low volume shrinkage, and minimal linear shrinkage. Despite its poor mechanical properties, with compressive strength significantly higher than tensile strength, iron is favored for creating complex shapes, asymmetric structures, and intricate parts.
Gray Iron Castings - Gray Iron has excellent castability and machinability and is known for its low production cost and compressive strength. As with various non-ferrous metals, cast iron has exceptional thermal conductivity and retains its dimensional stability at high temperatures. It is a fragile metal with low impact and tensile strength.
Ductile Iron Castings - Ductile iron has good fluidity with large shrinkage, which makes it susceptible to shrinkage cavities and porosity. Unlike gray casting iron, ductile casting iron has good mechanical properties with abrasion and impact resistance and fatigue strength.
Malleable Iron - Malleable iron is white cast iron that has been annealed, which transforms the brittle structure of white cast iron into a malleable one. As its name indicates, malleable iron has excellent ductility, machinability, toughness and corrosion resistance. Like most iron, malleable iron rusts but is used to produce hand tools, pipe fittings, brackets, and electrical fittings. Aside from its susceptibility to rusting, malleable iron has a poor strength to weight ratio.
Mild Steel
Mild steel is a low carbon steel composed of iron, carbon, and other elements. With a carbon content ranging from 0.15% to 0.30%, it is highly malleable and ductile. Increasing the carbon content enhances its hardness, strength, and hardenability. Widely used in sand casting due to its affordability and ease of work, mild steel can be machined, forged, and welded, making it suitable for various engineering projects. However, common issues with mild steel include sand inclusions, air holes, cracks, and shrinkage.
Stainless Steel
Stainless steel is a popular choice for sand casting due to its exceptional properties, including resistance to corrosion, durability, and strength. Its low coefficient of thermal expansion makes it ideal for applications requiring exceptional accuracy, high tolerance, and dimensional stability.
Despite its toughness and strength, stainless steel has a density of 7.8 grams per cubic centimeter, making it a relatively lightweight metal for casting essential parts. However, it is expensive due to its chromium and nickel content. Additionally, the high strength and stiffness of stainless steel can make it challenging to eject parts from the sand casting mold.
Alloy Steel
Alloy steel is produced by combining carbon steel with elements such as cobalt, chromium, manganese, nickel, tungsten, molybdenum, or vanadium. These alloying elements modify the steel’s strength, hardness, and corrosion resistance. Alloy steel generally exhibits excellent ductility, wear and shock resistance, strength, and toughness, though it can be more challenging to machine, form, and weld compared to carbon steel.
Alloy steel is used extensively across various industries to manufacture parts that must withstand significant stress, including automotive components, structural supports, pipelines, and ship components and structures. Its cost-effectiveness, being lower than that of stainless steel, contributes to its wide usage.
Chapter 5: What considerations should be taken into account when performing sand casting?
When considering sand casting design, it's important to understand the intended use of the casting and any additional processes it will undergo after pouring. For visible castings, a smooth finish might be required through machining or coating. If the casting is part of a structure or assembly that demands high stiffness, heat treatment services might be necessary.
To achieve the desired final results, most castings will need to undergo some form of machining or treatment. Essential considerations include:
Detailed Prints and Drawings
The most significant feature of sand casting mold design is the provision of extremely detailed prints and drawings. A sand foundry requires a drawing for both the casting and the fully machined product.
Detailed prints are a crucial communication tool in the sand casting design process, as they convey the designer's expectations and requirements for the finished product. The following information should be included in your sand casting product design:
Size
Shape
Draft
Radii
Tolerance level
Defect level
Surface finish
Inspection requirements
When your casting design includes cast-in identification marks like a component number, foundry code, or heat lot, ensure that the size and location are clearly indicated in your detailed drawings.
Sand Casting Draft Angle
The draft angle in sand casting is a critical angle applied perpendicular to the model to facilitate easy removal of the casting from the fragile sand mold without damaging the external surfaces. Factors such as the molding process, casting design, and the depth of the pattern within the mold help determine this angle. However, many designers often overlook its importance. Choosing an appropriate draft angle can enhance the effectiveness of the tapered surfaces in the casting design.
Moreover, due to the optimized metal flow, it can contribute to reducing processing costs. Therefore, adhering to the ISO standard for draft angles in sand casting is essential and does not compromise the functionality of the design. This practice allows for more efficient mold production at lower costs while maintaining quality. Typically, the standard draft angle for sand casting is 2 degrees, with a minimum draft of approximately 1 degree for both external and internal features.
Rounds and Filet
Incorporating ample rounds and fillets is a crucial element of the sand casting design process. Properly designed rounds and fillets not only improve the visual appeal of a casting but also help in evenly distributing stress and minimizing casting-related stresses. Well-placed corner fillets further contribute to the casting process by preventing turbulent flow and ensuring that the molten metal flows smoothly to fill the mold correctly.
Parting Line
In sand casting design, accurately determining the parting line is essential. This line acts as the division point where the mold separates, and its placement is crucial as it influences both the production cost and the quality of the castings. It is important for engineering designers to clearly define and document the parting line on the casting blueprint. Relying solely on the practical experience of foundry workers for this decision may not be sufficient.
The parting line should ideally be positioned as low as possible, and the design should aim for a wide, short, and flat line. If the parting line does not align with the seam burrs, the tolerance between them should not exceed 0.020 inches.
Moreover, the maximum flash extension material for the parting line should be around 0.015 inches. If the parting line's location changes, it's important to take note, as it can affect factors such as the use of cores, the pouring position, the casting's weight, and its dimensional accuracy.
Alloy Selection
Selecting the appropriate alloy for your casting is essential, as the choice of alloy can significantly influence properties such as:
Strength
Durability
Toughness
Corrosion resistance
Ductility
Shrinkage
Hardenability
Cost
Weldability
Undercuts and Cores
In sand casting design, the undercut feature is used to ensure that the pattern can be removed without damaging the mold during production. However, using cores can increase both the time and cost of casting. Therefore, it's important to minimize or eliminate the need for core sand sections in the design. Initially, experts provided guidelines for defining the parting line, which helped in understanding product features and avoiding undercut issues. Over time, these guidelines have evolved, making it crucial to understand the current norms and standards in sand casting design.
Cross-Sections
Maintaining a uniform cross-section or wall thickness is typically beneficial. However, in sand casting design, it might not always be feasible since many casting products cannot accommodate sudden changes in section thickness. Ideally, the thicker parts of the casting should not cool in isolation, as the cross-section is most effective when it remains uniform. This is because thicker sections take longer to cool.
Thicker sections are not influenced by the solidification of the surrounding metal and will be the last to solidify. This can lead to casting defects such as porosity or tearing if not properly managed. Therefore, it's crucial to account for the maximum allowable thickness in your sand casting design to avoid these issues.
Wall Thickness
In sand casting design, achieving uniform solidification and preventing cavity formation is essential. This involves managing the volume-to-surface area ratio of the mold. Generally, the rate at which castings solidify should be proportional to the square of this ratio.
Parts with a smaller volume-to-surface area ratio solidify more quickly compared to those with a larger ratio, and vice versa. To address this, many foundries either increase the overall thickness of the mold or add materials to support load-bearing areas. However, a more effective solution is to use stiffeners and gussets. Stiffeners enhance structural strength, while gussets help reduce local wall thickness, ensuring a more consistent solidification process.
Corners and Angles
The cooling characteristics of the material used for sand molds play a crucial role in the quality of sand castings. Therefore, this factor must be carefully considered during the design phase. Inadequate cooling of either the casting or the sand mold can lead to localized heat buildup at sharp corners and junctions of the component.
This localized heat concentration creates stress points, which can cause distortion, shrinkage, and cracking in the casting during subsequent processing, ultimately compromising the quality of the final product. It's important to address these issues in the sand casting design to avoid such problems.
Junction Design
The complexity of sand casting mold design allows for highly intricate part shapes, often involving various junctions. These junctions, such as L, X, V, Y, and X-T types, create local mass concentrations. Such concentrations can lead to issues like cracks, shrinkage, and strain. The best approach in sand casting design is to minimize these localized mass concentrations caused by junctions, ensuring they integrate smoothly into the final product.
Casting Allowance
Initially, it’s important to understand that metals like steel, copper, aluminum, magnesium, and zinc experience shrinkage as they solidify. When managing sand casting design, it’s crucial to include a machining allowance at the junctions between two sand castings.
In essence, avoid curved edges at the interfaces of sand castings. This is because shrinkage is related to the material's freezing point and the ratio of the casting's surface area to its volume.
Recycling Molding Sand
After removing the sand from a completed casting, the lumps are cooled and then crushed. A magnetic field is commonly employed to extract all metal particles and granules. Shakers, rotary screens, and vibrating screens are used to sort the sand and components. The cleaned sand is then reintroduced into the molding sand production process.
Mullers are utilized to mix sand with bonding agents and water for creating molding sands. Aerators are used alongside these mixers to loosen the sand, enhancing its moldability. Scoop trucks or belt conveyors transport the prepared sand to the molding area, where it is shaped into molds. These molds can either be placed on the floor or moved to a pouring station via conveyors. At the shakeout station, castings are separated from the residual sand after pouring. The used sand is then returned to storage bins via belt conveyor or other methods.
In the manufacturing process, casting sand is often reclaimed and reused. Industry estimates suggest that around 100 million tons of sand are used annually, with only four to seven million tons being discarded. Many companies also repurpose even the discarded sand.
Chapter 6: What are the applications and advantages of sand casting?
This chapter explores the various applications of sand casting and highlights its benefits.
Applications of Sand casting
The applications of sand casting are:
Pump bodies
Bearings
Bushings
Air compressor pistons
Impellers
Electronic equipment
Engine crankcases
Fittings
Engine oil pans
Gears
Flywheel castings
Gas and oil tanks
Machine parts
Advantages of Sand Casting
Despite its advantages, sand casting has some drawbacks, including:
Low material strength - When compared to a machined item, the material strength is low because of the excessive porosity.
Low dimensional precision - Dimensional accuracy is particularly poor when shrinking and finishing the surface.
Flaws are unavoidable - Defects or quality differences, such as shrinkage, porosity, pouring metal defects, and surface defects, are inherent in any metallurgical process. When compared to other casting methods like die casting and investment casting, sand casts have a high level of porosity.
Post-processing — if a tighter tolerance is necessary to interface with other mating parts, a further machining operation is frequently required. In comparison to tooling and material costs, processing costs are significant.
However, the benefits of sand casting often outweigh its disadvantages. Key advantages of sand casting include:
It is used to form complex shapes
It can produce very large parts
Very low cost for tooling
Recycle scrap
It is versatile and applicable to all metals, including high melting point ones.
Easy to scale
Complex geometries with thin-wall sections
Low production cost
Complex geometries with thin-wall sections
Conclusion
Sand casting is a manufacturing process in which liquid metal is poured into a sand mold, which contains a hollow cavity of the desired shape, and then allowed to solidify. When casting, a liquid material is poured into a mold, which then solidifies to give the desired shape. Casting materials include metal, concrete, epoxy, plaster, and clay. It is essential to select the right method/technique in sand casting, cognizant of the type of sand intended for use.
Leading Manufacturers and Suppliers
Related Posts
Aluminum Casting
Aluminum casting is a method for producing high tolerance and high quality parts by inserting molten aluminum into a precisely designed and precision engineered die, mold, or form. It is an efficient process for the production of complex, intricate, detailed parts that exactly match the specifications of the original design...
Die Casting
Die casting is a high pressure metal casting process that forces molten metal into a mold. It produces dimensionally accurate precision metal parts that have a flawless smooth finish...
Permanent Mold Castings
Permanent molding casting is a casting process that uses strong durable reusable molds to produce parts and components using molten metals. The molds for permanent mold casting are made from steel or...
Zinc Die Casting
Zinc die casting is a casting process where molten zinc is injected into a die cavity made of steel that has the shape, size, and dimensions of the part or component being produced. The finished cast zinc product has...
Types of Casting Processes
The casting process is an ancient art that goes back several thousand years to the beginning of written history. The archeological record has finds that document the use of the casting process over 6000 years ago around 3000 BC or BCE...
Cold Forging
Cold forging is a metal shaping & manufacturing process in which bar stock is inserted into a die and squeezed into a second closed die. The process, completed is at room temperature or below the metal‘s recrystallization temperature to form a metal into a desired shape or configuration...
Forging
Forging is a metal working process that manipulates, shapes, deforms, and compresses metal to achieve a desired form, configuration, or appearance outlined by a metal processing design or diagram...
Investment Casting
Investment casting is a metal working process that uses a ceramic shell built over a wax pattern to produce parts with extraordinarily uniform and smooth surfaces. The wax pattern is produced from an aluminum die.The final products of investment casting are without parting lines, mold half marks, or other deformities...
Iron Castings
An iron casting is a hard product obtained from combining iron with carbon. This can be readily cast in a mold, and it contains a higher proportion of carbon compared to steel. The proportion typically ranges from 2 to 4.3...
Lost Wax Casting
Lost wax casting is a casting process that uses a wax pattern to create a ceramic mold for creating a part or product design. It has been known over the years as lost wax or precision casting due to its accuracy in recreating parts with precise tolerances...
Open vs Closed Die Forging
In this article, there are key terms that are typically used with open and closed die forging and it is necessary to understand their meaning. Forging is a process in manufacturing that involves pressing, hammering, or...
Rolled Ring Forging
Rolled ring forging is a metal working process that involves punching a hole in a thick, solid, round metal piece to create a donut shape and then squeezing and pressuring the donut shape into a thin ring...
What is Forging?
The ancient art of forging falls into two distinct categories – hot and cold where hot forging has been around for centuries while cold did not begin until the industrial revolution of the 19th Century. Though they are quite different ...
